Pole Bands Mounting Clamp

Contact on whatsapp

Description

Technical Parameters and Drawings

Range Dimension Thickness Width
Code mm inch A mm B mm mm Light mm Medium mm Heavy mm
HEPB06X 127-152 5-6 152 127 6 38 50 65
HEPB07X 152-178 6-7 178 152 6 38 50 65
HEPB08X 178-203 7-8 203 178 6 38 50 65
HEPB09X 203-229 8-9 229 203 6 38 50 65
HEPB10X 229-254 9-10 254 229 6 38 50 65
HEPB11X 254-279 10-11 279 254 6 38 50 65
HEPB12X 279-305 11-12 305 279 6 38 50 65
HEPB13X 305-330 12-13 330 305 6 38 50 65
HEPB14X 330-356 13-14 356 330 6 38 50 65
HEPB15X 356-381 14-15 381 356 6 38 50 65
  • Codeexplaination: HEPB06L-2A means light duty with 2A type.

Notes:

1. Tolerance: ±5%
2. All dimensions are in MM except for marked.
3. Finish: steel hot dip galvanized per ASTM A153
4. Customized sizes are available at request.















Product Description:

Secondary rack pole bands are produced to joint secondary racks to tubular steel or wood poles.
There are two types. Single cup type pole bands are designed to  attach one rack.
Pole bands are produced in carbon steel SAE 1010 to 1020, hot dip galvanized to ASTM A-153.
Pole bands are supplied with 3 carriage bolts, 3 spring washers and 3 square nuts.
Carriage bolts are to attach the racks and tighten bands on a wide range of wood or steel poles.


The above are typical only, please consult Shanghai Herrajes for further information.


Product Details:
Name: secondary rack pole bands single type, pole clamps, one cup clamps
HS code: 7326909000
Model: Single
Package: bulk packing; palletized; as required
Trademark: HE, as required
Origin: China
Raw material: ASTM A536
Finish: hot dip galvanized
ODM&OEM service: yes
Sample: available, FOC
Payment term: T/T, 30% prepayment and 70% balance against B/L
Certificate: ISO
Delivery time: 20-40 days
MOQ: 500kgs
Export term: FOB; CIF
Production capacity pcs/day: 2000
